Are you looking for a solution to reduce delivery time by eliminating post-frac interventions and improving real-time efficiency at the wellsite? The truth is that in the current energy sector landscape, achieving limits is quite challenging. So, have you ever considered how to streamline the plug-and-perf operational line without incurring any risk of cost or investment? If not yet, here is the solution for you: Dissolvable frac plugs. It is a proven solution that comes with a faster and cleaner operational line. It is a good investment to ensure the reliable completion of the project across any healthy environment, as it is designed with specific materials that dissolve after every use. This eliminates the need for milling to maintain efficient performance under pressure.
Furthermore, the guide is here to help you get more aware of the terms associated with the frac plugs, and how they are capable of restoring the most outstanding value based on modern demands.
Dissolvable frac plugs are wellbore essentials, which are designed to temporarily isolate the stages while executing the operations of hydraulic fracturing. These are a special type of frac plus, not similar to metallic and composite plugs. The dissolvable frac plugs come with additional perks and benefits. To try it once, first scan the sections below to gain a deeper understanding of the same.
In this section, you will learn about the operational process for operating on dissolvable frac plugs. Let’s get into it without wasting much time:
Deployment: Initially, the frac plug is put down into the wellbore via wireline or a coiled tubing system, as per the suitability.
Seating: It is placed to lock the space inside the casing by creating a shield to the specific section of the wellbore.
Fracturing: Next, the fluid is pumped into the well under high pressure with the motive to break the rock and release the required oil or gas from the small holes section inside the casing.
Dissolution: Once the job is done, the plug will start breaking down by itself when it comes in contact with the fluid inside the well.
Production: After the successful dissolution, oil or gas will start flowing with no need to eliminate anything from inside the well.
The latest plug designs, like the Wizard Disoluble plug, can further optimise the operational procedure by eliminating the elastomers with the dedicated use of metal seals.
● No Post-Frac Intervention: No milling or pulling equipment required.
● Reduced Risk: Simplified design significantly reduces preset failure or sticking events.
● Reduced Completion Time: Reduction in post-frac phases leads to quicker well turnarounds.
● Environmental Benefits: Reduced trips and interventions mean fewer emissions and less environmental impact.
● Proven Versatility: Can be used in temperature and pressure ranges and acid-rich or high-TDS environments.
For example, Wizard Dissolvable Plug has reduced completion costs and time by 15–22% across thousands of successful deployments globally.
FEATURE | DISSOLVABLE FRAC PLUGS | COMPOSITE PLUGS | METALLIC PLUGS |
Post-Frac Removal | Self-dissolves in fluid | Requires milling | Requires milling |
Operational Time | Faster | Slower due to cleanout | Slower due to cleanout |
Material Composition | Magnesium alloy, polymers | Composite & elastomers | Full metal |
Risk of Getting Stuck | Low (fewer components) | Medium | High |
Cost of Intervention | None | Moderate | High |
Environmental Impact | Low | Moderate | High |
Ideal Use Cases | Multi-stage horizontal wells | Conventional completions | Specialized or legacy wells |
The above comparison highlights why so many modern and advanced operators prefer dissolvable frac plugs, especially for time-sensitive projects.
As per the above discussion, we can say that the dissolvable frac plugs are rapidly innovating the thriving completion by eliminating the unnecessary interventions and the operational risks. To achieve such efficiency, consider visiting Vertechs to explore the available solutions that enable faster turnaround times, reliable performance, and minimal environmental impact.
For more information on the Wizard Dissolvable Plug or anything related, or even to request technical consultation, contact the expert’s team at Vertechs via engineering@vertechs.com
